Export Custom Field

Hi All, I have a bib file with several custom fields and I want to export to csv format. I did follow the page

but it is not clear on how as I modify the layout to include one custom field but when export it doesnt work.

I copy here as example of one reference, but i have like hundreds of entries with different types such as Contract, Lease, Memo, Letter, etc.

@CONTRACT{AVIVA2017,
groups = {LE03},
title = {Appointment Contract of Mechanical and Electrical Services Engineer},
year = {2017},
month = {#dec#},
date = {2017-12-21},
organization = {Aviva Life & Pensions UK Limited},
timestamp = {2024-09-13},
comment = {No clear title the document title has been created},
asset = {Category A Fitout of 4th floor office},
author = {(1) AVIVA and LIFE and PENSIONS UK and LIMITED},
category = {Legal},
contractor = {Watkins Payne Partnership},
discipline = {Legal},
file = {},
must = {Y},
requirement = {Legal},
stage = {Pre-Construction},
validity = {NA}
}

Thanks for help.
Nam

Hi,

you need to copy the layout files to a new directory, modify the layout files to include your field
and add them as in the documentation as new custom exporter

Thanks Christoph,
I follow this link but found very difficult to implement as there are two files
Appreciate if you can advise me on the step by step.
Let say I only need to add new custom fields name Asset and Organization along with Title so what should I do in that two files, can I do smt like follow

Begin Layout

BibliographyType,Title,Organizations,Asset

ENd layout

\format[GetOpenOfficeType]{\entrytype},{\title}“,”\organization",“Asset”

After i modify that two layouts what will be next step.

I go to Preference → Custome Export Format → Add

then after I click Add, it appers 3 fields to enter

  • Export Format Name → I type begin layout

  • Main layout file → I choose the begin layout

  • File extension → I type csv
    then I add another one

  • Export Format Name → I type end layout

  • Main layout file → I choose the end layout

  • File extension → I type csv

Can you advise if those steps are correct?
and Can I save those two layouts in any folder or it has to be saved under some rooted folder of Jabref.
Thanks

Nam

Hi,

  1. Copy the existing layout files from jabref/src/main/resources/resource/layout/openoffice at 7e69ef57ce1e1b66a2dfd44b9a5c0d43dfd41c3b · JabRef/jabref · GitHub to a new folder on your computer, doesn’t matter where e.g. mycustomcsvexporter
  2. Modify the begin.layout, add your new column headings for the fields e.g. “Asset”
  3. Modify the openoffice-csv.layout add the new field command e.g. \asset
  4. Add a new custom exporter in JabRef MyCustomCSVExporter with file extension csv
  5. As main layout file select the openoffice-csv.layout
  6. Now you can use your new exporter

JabRef automatically checks for optional begin.layout and end.layout files in the folder.
The begin.layout usually contains some fixed “header” stuff, for example the first line in csv or the beginning of a html document.
And end.layout often contains some “footer” stuff, e.g, the document end tag of a HTML document.

I follow the step you mentioned but it seems I miss a critical step somewhere.
I decided to record the video in the following link and appreciate if you can give me advice.

I copy as well here the content of bib file

% Encoding: UTF-8

@Po{Display2023,
asset = {Mill Lane Industrial Estate},
category = {Operational},
date = {14},
discipline = {FDAS},
groups = {NA},
month = {December},
must = {N},
organization = {Midland Fire Solutions Limited},
requirement = {Best Practice},
stage = {Maintenance},
timestamp = {2024-09-12},
title = {Fire Extinguisher 2024},
year = {2023},
author = {Premier Display},
}

@TechReport{Garment2024a,
asset = {New Star Road State},
category = {Operational},
discipline = {Civil},
groups = {NA},
must = {N},
organization = {Hexa Consulting Limited},
requirement = {Best Practice},
stage = {Design},
timestamp = {2024-09-13},
title = {RAAC Inspections Charles Street Buildings Group},
year = {2024},
author = {James Garment},
}

Two things:
When Exporting chose your custom exporter “MyCustomExporter” for file type!

abd he field must be lowercase \asset

1 Like

Many thanks Christoph, it works now. :grinning: When you visit Vietnam, I own you a well treat. Please contact. This is the best software and I have used it for the last 10 years.

2 Likes

Thanks for the kind words! I will keep that in mind :grinning:

This is the best software and I have used it for the last 10 years.

Thanks again!

PS: If you like to give something back, you could consider a donation: donations.jabref.org.

Danken Christoph,
Already did :grinning:

2 Likes
